Height & complex Slew Limitation
PME400

Maximise asset performance and regulator compliance with KINSHOFER Prolec's HS Pro, setting the UK standard for Height & complex Slew Limitation

Suitable for

  • Excavators - multiple articulations
  • Mobile Cranes (EN13000:2010)
  • Truck mounted cranes
  • Agricultural machinery
  • Special purpose machines

Benefits

  • Fully compliant to relevant standards
  • Enables your construction equipment to work on sites operated by major infrastructure companies
  • Easily upgradeable to include RCi, machine guidance
  • Full data logging (up to 30 days)

Features

  • Real-time machine position monitored and controlled to provide an immediate warning on approach to set limit
  • Audible and visual alarm at and on approach to set limits
  • ‘Always on’ controller monitors and stores machine state ensuring complete traceability
  • Full data logging of all actions including alarms, approach to set limit warnings
  • Simple or complex height & slew limits can be set to match working profile such as within tunnels
  • Displays safe movement options when at or nearing set limit
  • Soft Override if operator deems safe
  • Override Keyswitch
  • SIL1 safety version as standard. SIL2 as an option

Options

  • External alarm and beacon
  • Offset boom variants
  • SIL1 safety version as standard. SIL2 as an option
  • Upgradeable to include, RCi, machine guidance

Fully engineered for compatibility with all major manufacturers, the system maximises the machine’s productivity well maintaining compliance and safety.


PME400 is designed to control the movement of a machine in all planes; vertical and horizontal providing a 3D envelope of control around the machine.  Offering multiple options for control, this system combines the slew sensing of PME300 with the 2D envelope monitoring of PME100 in one integrated solution.  As for other PME systems this system comes with a high resolution, daylight-viewable screen allowing multiple configurations of the envelope to be described, monitored and controlled.  Optional motion cuts on any hydraulic service are possible allowing both monitoring and control on the machine movement.  The operator will benefit from KINSHOFER Prolec’s easy to use Man Machine Interface 'MMI' integrated within the foundation of PME.


PME400 is a cost effective Height & complex Slew Limiter solution that does not compromise on quality or safety.
